Fully Modular.
.png)
-
80Plus Platinum Certification:
This top-tier certification guarantees exceptional energy efficiency, reducing heat output and lowering power consumption during demanding workloads. -
Active Power Factor Correction (PFC):
Stabilizes power delivery, even in varying input conditions, ensuring the system runs reliably and efficiently. -
Low Noise Operation:
Advanced Fluid Dynamic Bearing technology enhances cooling with 120mm Fan, ideal for users prioritizing silent performance. -
Alternative Sleep Mode (ASM):
Complies with ErP regulations, optimizing 5V standby efficiency for eco-friendly performance in sleep states. -
PCI-E CEM5 Support:
Provides scalability for power excursions, catering to graphics-heavy gaming and workstation systems. -
High Reliability in Tough Environments:
Operates seamlessly from 0°C to +40°C with automatic performance adjustment at higher temperatures, ensuring consistent functionality in challenging conditions.
.png)
| Input Rating |
DC output Rating |
• Input Voltage : 100 - 240V• Input Current : 15..0 - 7.0 A• Input Frequency : 50 - 60 Hz
|
• 12V : 100A (1200W)• 5Vsb : 3A (15W)• 3.3V & 5V : 20A (100W)• -12V : N.A• Total Output Power: 1200W |
Power Efficiency |
Protections |
• 80Plus Efficiency: Platinum• 2% Loading: 60% @ 115V• 10% Loading: reference only• 20% Loading: 90% @ 115V• 50% Loading: 92% @ 115V• 100% Loading: 89% @ 115V |
• OVP (Overvoltage Protection)• OCP (Overcurrent Protection)• SCP (Short Circuit Protection)• OTP (Over Temperature Protection)• OPP (Overpower Protection) |
Operation |
|
• Operating Temperature: 0 - 40 °C• MTBF : 100,000 hours |
.png)
- Dimension：150(W)x130(L)x86(H)mm
- 120mm Cooling Fan
- Protection：OVP、SCP、OPP、OCP、OTP
.png)
