80Plus Platinum Certification:
This top-tier certification guarantees exceptional energy efficiency, reducing heat output and lowering power consumption during demanding workloads. -
Active Power Factor Correction (PFC):
Stabilizes power delivery, even in varying input conditions, ensuring the system runs reliably and efficiently. -
Low Noise Operation:
Advanced Fluid Dynamic Bearing technology enhances cooling with 120mm Fan, ideal for users prioritizing silent performance. -
Alternative Sleep Mode (ASM):
Complies with ErP regulations, optimizing 5V standby efficiency for eco-friendly performance in sleep states. -
PCI-E CEM5 Support:
Provides scalability for power excursions, catering to graphics-heavy gaming and workstation systems. -
High Reliability in Tough Environments:
Operates seamlessly from 0°C to +40°C with automatic performance adjustment at higher temperatures, ensuring consistent functionality in challenging conditions.
.png)
Input Rating |
|
DC output Rating |
- Input Voltage : 100 - 240V- Input Current : 10.0 - 5.0 A- Input Frequency : 50 - 60 Hz |
|
- 12V : 70.8 A (749W)- 5Vsb : 3A (15W)- 3.3V & 5V : 20A (100W)- Total Output Power: 850W |
Power Efficiency |
|
Protections |
- 80Plus Efficiency: Platinum- 2% Loading: 60% @ 115V- 10% Loading: reference only- 20% Loading: 90% @ 115V- 50% Loading:92% @ 115V- 100% Loading:89% @ 115V |
|
- OVP (Overvoltage Protection)- OCP (Overcurrent Protection)- SCP (Short Circuit Protection)- OTP (Over Temperature Protection)- OPP (Overpower Protection) |
Operation |
|
|
- Operating Temperature: 0 - 40 °C- MTBF : 100,000 hours |
|
.png)
- Dimension：150(W)x130(L)x86(H)mm
- 120mm Cooling Fan
.png)
|
|
|
Datasheet |
