Industrial Chassis
YCC-2600
Instructions
specification
| Model Name | YCC-2600 |
| Form Factor | 2U |
| Material | 1.0 mm SGCC |
| Motherboard | Micro-ATX (9.6" x 9.6") and below |
| Drive Bay(Internal) | 3.5" x 4 (compatible with 2.5" x 3) |
| Power Supply | ATX PS2 (Or you can place the HDD cage horizontally if using longer ATX PSU.) |
| Cooling system |
Front：80mm x 3
|
| Expansion Slot |
4
|
| Front I/O Port | USB 2.0 x 1 + USB 3.0 x 1 |
| Indicators | Power LED x 1 + HDD LED x1 |
| Control lights Key | Power switch x 1 + Reset switch x 1 |
|
Dimension
|
380 x 430 x 89mm (D x W x H)
|
